Wind energy, as a kind of clean and renewable energy, is increasingly favored by people, and wind power generation is a main form of wind energy utilization. The rapid growth of wind power demand and the prospect of further growth, led the development of wind power equipment industry. The wind power system transformer produced by our company has accounted for our company annual output value of more than 30%, after continuous improvement, the series of products of small size and light weight, low loss, high cost performance, gained wide recognition from customers.

1 using standard: 1094.11-2007 GB, 1094.16-2013 GB

2 rated capacity: 10-1600kVA

3 rated voltage: 690V, 400V, 230V, etc.

4 insulation class: F or H

5 linkage groups: according to customer requirements

The use of the environment: 6 - altitude: 2000m - to adapt to the environment temperature: -10~ 45 degrees

- suit for relative humidity: less than or equal to 95%

The use of the environment: indoor (please provide protection for outdoor use.)

The core is made of high quality cold-rolled silicon steel sheet carefully laminated from insulation according to different levels, the whole vacuum impregnation different insulating paint grade, effectively reduce transformer noise, reduce the influence of salt spray, mold of transformer.
